CM-2020-HDU3 Full HD PTZ Camera
The CM-2020-HDU3 combines precision optics, smooth PTZ control, and multi-protocol connectivity. It is engineered for conferencing, education, broadcasting, and command environments.
Built for clarity, reliability, and versatility, the CM-2020-HDU3 delivers Full HD 1080p60 video, wide-angle coverage, and flexible optical zoom options (5X–30X). With seamless integration into corporate AV, lecture capture, live streaming, and surveillance setups, it adapts to virtually any application.
The CM-2020-HDU3 offers advanced PTZ control with HDMI, SDI, USB, LAN, and optional Wi-Fi, plus support for RTSP, RTMP, ONVIF, and GB/T28181 streaming. Its compact design and quiet motors deliver smooth, precise operation.
With 255 presets, dual audio input, and smart imaging features like auto focus, exposure, and noise reduction, it ensures reliable performance across boardrooms, classrooms, studios, and command centers.
Key Features
Full HD 1080p60
Smooth, lifelike video quality
Zoom Options
5X–30X optical zoom with 83.7° wide angle
Intelligent Imaging
AWB, AE, AF ensure optimal imaging in all conditions
Noise Reduction
2D/3D DNR for low-light performance
Multiple Outputs
HDMI, SDI, USB 2.0/3.0, LAN, optional Wi-Fi
Streaming Ready
ONVIF, RTSP, RTMP, GB/T28181 support
Smooth PTZ Movement
Silent motors for precise control
255 Presets
Store and recall positions instantly
Specifications
General
- Model Number: CM-2020-HDU3
Camera Parameters
- Image Sensor: 1/2.8” CMOS, 2.07MP
- Resolutions: Up to Full HD 1080p60
- Video Formats: 1080p60/50/30/25, 720p60/50/30/25
- Optical Zoom: 20X (optional models: 5X–30X)
- Digital Zoom: 10X°
- Field of View: Up to 83.7° (wide)
- Pan/Tilt Range: Pan ±170°, Tilt -30° ~ +90°
- Pan Speed: 1.7°–100°/sec
- Tilt Speed: 1.7°–69.9°/sec
- Preset Positions: Up to 255
- Auto Adjustments: Auto White Balance (AWB), Auto Exposure (AE), Auto Focus (AF)
- Noise Reduction: 2D & 3D Digital Noise Reduction
Interfaces & Outputs
- Video Outputs: HDMI, 3G-SDI, USB 2.0/3.0, LAN, Wi-Fi (optional)
- Audio Input: Dual-channel 3.5mm jack (AAC, MP3, G.711A codecs)
- Control Ports: RS232 / RS485
- Control Protocols: VISCA, Pelco-D, Pelco-P
- Streaming Protocols: ONVIF, RTSP, RTMP, GB/T28181
- UVC Support: Yes
Power
- Power Supply: DC 12V
- Power Consumption: Max 12W
- Operating Temperature: -10°C ~ +50°C
- Storage Temperature: -40°C ~ +60°C
- Dimensions: 156mm x 142 mm x 156 mm
- Weight: Approx. 1.4 kg
- Usage: Indoor
In the Box
- CM-2020-HDU3 PTZ Camera
- Power Supply
- RS232 Control Cable
- USB 2.0/3.0 Cable (model dependent)
- Remote Controller
- User Manual
- Mount (Extra Cost)
Warranty
- 2-Year Limited Warranty
